Z-Wave 24V AC 30W LED Driver

SRP-ZV9105-24-30CVT er en 24v LED-Driver med 2 kanaler. Denne kan brukes for både 1 farget eller 2 farget LED-Strips eller annen 24V LED-Produkter.

Features

• IP20 independent isolated driver, for indoor use
• Communicates via Z-Wave Plus RF (868,42 MHz)
• RF Range Typical: 30 meters
• Group for Association: 1 (Max 5 nodes)
• Supports encryption mode: S0, S2
• Support: Beaming and Z-Wave explorer frames
• Over The Air (OTA) firmware upgrades
• Functions Control: Switch ON, switch OFF, DIM
• LED Channels: 2
• Dimming Method: Pulse Width Modulation (PWM)
• Output type: Constant Voltage (CV)
• Rated Output Current (24V DC): CH1 + CH2 = 1,25A
• Max Load (2 Channels) = 50W combined
• Overcurrent and Temperature Protection
• Suitable for Dump Locations
• SELV, LED Class 2 Power Supply
• Smooth and deep dimming to 0.1%
• Supplied with terminal cover and cable retainer
• Class Ⅱ protection against electric shock for direct or indirect contact
• SELV compliant
• Protections:
  - against overheating and short circuits;
  - against mains voltage spikes;
  - against overloads;
  ·Withstand voltage: I/P-O/P: 3.75KVAC
  ·Surge immunity Line-Line 0.5KV
